Motor Type(모터종류)

Stepping Motor

RPM(회전속도)

0.1 ~ 600 (100~600 RPM은 최대 50 RPM 단위로 설정가능)

Flow Capacity(유량범위)

0.06 to 2,900 mL/min [(Full Range), (튜빙 사이즈에 따라 다름)]

사용온·습도

Temperature : 0~50℃, Relative Humidity<80%

Housing Materials

ABS Plastic Case / PET 액정보호필름

Display

4 Digit LED Display(RPM or Timer)

System Power

230VAC, 60Hz

Dimensions(W×D×H)

180×210×200mm (펌프헤드 제외)

External Interface

Input : Internal/External, Stop/Start, CW/CCW, Speed(4~20mA or 1~5V), Leak Sensor
Output : Alarm, Pumping, Direction(CW/CCW)

Applied Pump Head

EMH-1000, Easy-LoadⅠ, Easy-LoadⅡ, Easy-LoadⅢ, Standard, AMC Series, DG Series

작동모드

RPM : 0.1 ~ 600, Timer : 00:01 ~ 99:59

Weight

약 4 kg

EMH-1000

Pump Head for EMT-Series, L/S Series (#13, #14, #16, #25, #17, #18)

EMT-FS-100L

Foot Switch for EMP-600A Series & EMP-650IP

LD-2000

Liquid Leak Detector(액체누수감지기) for EMP-600A Series & EMP-650IP

Tubing Size

#13

#14

#16

#25

#17

#18

ID(mm)

0.8

1.6

3.1

4.8

6.4

7.9

사용유량(mL/min)

0.06 ~ 36

0.21 ~ 130

0.8 ~ 480

1.7 ~ 1000

2.8 ~ 1700

3.8 ~ 2300

Maximum Pressure(bar)

2.7

2.4

1.4

1.0
